Use AI to review your drawings

Manual reviews of drawings is a major bottleneck in the industrial design process. It is time-consuming, with a large risk for errors. Our AI engine reads and interprets technical drawings. Combined with data from your other systems this allows us to perform automated reviews and quality-checks of drawings. This leads to:
  • Higher-quality of drawings
  • Fewer costly R&D iterations, both internally and externally
  • Time savings for designers and reviewers
  • Retained and enhanced expertise for design policy compliance
  • Simplified documentation and follow-up
  • A happier engineering team

How AI Review works

Similar to how other AI systems find people, dogs, and cars in images, our AI Review system finds objects, symbols and information in drawings. Using extensive knowledge of CAD, and experience from reviewing tens of thousands of drawings, it raises alerts when a drawing contains errors. It’s like having a senior engineer that’s always ready to review your drawings, at any hour every day of the year.

Using AI Review

Once a design is ready for review, the AI system checks it, finding errors and ensuring that the design follows your company design guidelines. Errors found are annotated in the drawing and summarised in a report.

AI Review can either be integrated with your PLM system or business system, or be used as a stand-alone web-based application.

Customize AI Review according to your company's guidelines

With more than 50 standard rules available, you can get started quickly. If like most of our customers you also want rules custom to your organisation, we’re happy to help tailor rules to your design policies or derive rules from your historical data using machine learning.

AI Review helps you with ISO GPS and ASME Y14

AI Review checks the use of geometric dimensions and tolerances (GD&T) on your drawings and ensures compliance with your standard. The system already supports parts of ISO GPS and ASME Y14, and in collaboration with our clients, we continue to add support for new parts of the standard.
